Novation Summit 16-Voice Polyphonic Keyboard Synthesizer
Built on the innovative foundations of Novation's critically acclaimed Peak synthesizer, Novation Summit is a three-oscillator-per-voice, 16-voice keyboard synth aimed at the professional or semi-professional musician seeking an inspiring, empowering instrument for use both live and in the studio. Summit effectively puts the power of two Novation Peaks at your fingertips, enabling two completely independent patches to be split or layered across the keyboard or switched between on the fly. It also expands on Peak's layout, with many 'hidden' controls and functions made accessible on the front panel – FM routing, LFOs 3 and 4, all arpeggiator parameters and more – plus the addition of pitch and mod wheels. Summit also features numerous new filter options and an audio input for processing external sources with its reverb, chorus and delay effects.
At the heart of Summit are three digital New Oxford Oscillators per voice, hosted on a FPGA (field-programmable gate array) chip. As well as generating authentic analog-style waveforms at incredibly high resolution, this also facilitates FM and wavetable synthesis for the design of rich, complex and highly textural raw tones. Each voice feeds into a true stereo signal path comprising dual analog filters, three stages of analog distortion and analog VCAs while a wealth of modulation assignment options and three colorful effects bring movement, life and polish to your patches.
- 16-notes of polyphony (dependent on voices used per note)
- 2-part-timbral with layered, split and dual bi-timbral modes
- 5 voice modes: Mono, MonoLG, Mono2, Poly, Poly2
- Extensive mod matrix with 16 modulation slots per patch and 2 sources per destination per slot
- FM controls on front panel
- Arpeggiator with key latch and 33 patterns
- Microtuning with Scala table import and table tuning creation
- All knobs (excl. volume), sliders and most buttons transmit and receive MIDI CC commands for external control and mapping
Peak powered up
The acclaimed Novation Peak architecture has been taken to the next level in Summit with 16 voices, expanded front panel controls, new filter options, a five-octave keyboard and more.
Two sounds at once
Summit has a multitimbral engine for splitting, stacking and switching between two simultaneous patches.
Digital where it counts
Digital FPGA-generated New Oxford Oscillators provide analog-style, wavetable and FM synthesis.
Analog where it matters
Summit's oscillator output is passed through dual analog filters, analog VCAs and three stages of analog distortion per voice.
Per-part effects and arpeggiation
Process each part or an external audio signal with reverb, chorus and delay effects and create riffs and melodic lines with a variety of arp modes, adjustable gate time and preset patterns.
|Included from Manufacturer||Power cable
|Number of Keys||61|
|Key Action||Semi-weighted with velocity sensitivity and aftertouch|
|Programs/Presets||512 patch storage locations
Ships with 256 factory patches
|Voices of Polyphony||16|
|Oscillators per Voice||3|
3 chorus types
Delay with 16 types of delay sync, low pass and high pass damping, slew and stereo
|MIDI||In, Out, Thru, USB|
|USB Port (to Host)||MIDI, System Updates, Editor/Librarian/Patch Manager|
|Audio Inputs||Dual 1/4" stereo external audio input|
|Audio Outputs||Dual 1/4" stereo main output
Dual 1/4" stereo auxiliary output
1/4" stereo headphone output
|Control Connections||(2) 1/4" pedal inputs for expression pedals or footswitches
1/8" CV input
|Onboard Controllers||Pitch bend wheel
|Product Weight||23.99 lb|
Novation Limited Warranty
All Novation products are built to the highest standards and should provide reliable performance for many years, subject to reasonable care, use, transportation and storage.
Many of the products returned under warranty are found not to exhibit any fault at all. To avoid unnecessary inconvenience to you in terms of retuning the product please contact Novation support.
In the event of a Manufacturing Defect becoming evident during the warranty period, Novation will ensure that the product is repaired or replaced free of charge. The warranty period for any product purchased on or after January 24th, 2020 is a period of 36 months from the date of the original purchase.
A Manufacturing Defect is defined as a defect in the performance of the product as described and published by Novation. A Manufacturing Defect does not include damage caused by post-purchase transportation, storage or careless handling, nor damage caused by misuse.
While this warranty is provided by Novation, the warranty obligations are fulfilled by the distributor responsible for the country in which you purchased the product.
The distributor will advise you of the appropriate procedure for resolving the warranty issue. In every case it will be necessary to provide a copy of the original invoice or store receipt to the distributor. In the event that you are unable to provide proof of purchase directly then you should contact the reseller from whom you purchased the product and attempt to obtain proof of purchase from them.
Please note that if you purchase a Novation product outside your country of residence or business you will not be entitled to ask your local Novation distributor to honor this limited warranty, although you may request an out-of-warranty chargeable repair.
This limited warranty is offered solely to products purchased from an Authorized Novation Reseller (defined as a reseller which has purchased the product directly from Novation in the UK, or one of its Authorized Distributors outside the UK). This warranty is in addition to your statutory rights in the country of purchase.
